Product Detail

ControllerInput Voltage Range : 2s - 3s LiPo; 6 - 8 cell NiMH (6900kv motor is limited to 2s)BEC Specifications : 5.0 volts fixed, 2 amps.Operating Environment : Waterproof* design allows for use in nearly any environmentBrake : ProportionalReversible : Yes, but may be disabled for racing.On/Off Switch : YesCooling Fan : Available, but not includedESC Size : L: 1.93" (49mm)W: 1.48" (38mm)H: 0.79" (20mm)ESC Weight (w/wires) : 1.96 oz. (55.5 g)Connectors : 4mm female bullets for motor connection.Items Needed for Operation : Battery Connector required;Castle 4mm polarized connectors, Dean's Ultra Plug, or Traxxas Power Connector recommended.Product Use Statements : *Although Sidewinder 3 is waterproof, it is not intended for operation while completely submerged in liquid. They can corrode when exposed to corrosive materials, such as salt water. Always rinse the ESC with clean water after exposure to corrosives or dirt. While the controller may be waterproof, we suggest users confirm that the rest of their vehicle, including the batteries, servos, radio and chassis are also waterproof before exposing them to liquids of any kind.Application Guidelines : 1/10th scale on-road cars for 2s use.Lighter off-road 1/10th stadium trucks and buggies with conservative gearing.NOT for use in 2WD or 4WD short course trucks.Please refer to our Gearing Chart for recommended motor, battery and gearing for some of the more popular vehicles on the market.Recommended Motors : Combo includes Castle 1406-6900kv motor.Max. Recommended Vehicle Weight : No more than 4lbs with battery, ready-to-run.Programmability : Fully programmable Castle feature set using Castle Link USB adapter (sold separately) and freely downloadable Castle Link Windows software or the Castle Link iOS App and a B-LINK Bluetooth Adapter (sold separately).Telemetry Link Capable : NoTech Notes : Not all LiPos are created equal, and surge ratings should never be used to determine a pack’s suitability for a brushless application. Use the CONTINUOUS C rating only. Brushless setups frequently hit 100+ amps in peaks. We strongly suggest using 5,000 mAh or larger LiPo cells with a discharge rating of at least 30C (or high quality 25C batteries such as Traxxas® Power Cells®). Our experience suggests using only mild gear ratios with NiMH cells. Do not attempt to use NiMH cells in extreme setups.Motor Technical SpecsInput Voltage Range : 2S LiPoKv : 6900Max. RPM : 100,000Size : Length: 49.5mmDiameter: 36mmWeight (w/wires) : 193g / 6.8ozShaft Size : Length: 15mmDiameter: 1/8" (3.17mm)Mounting Hole Specifications : M3 @ 25mmCooling Fan : Optional, coming soon!Connectors : 4mm male Castle Bullet ConnectorsApplication Guidelines : 1/10th scale on-road cars for 2s use.Lighter off-road 1/10th stadium trucks and buggies with conservative gearing.NOT for use in 2WD or 4WD short course trucks.Please refer to our Gearing Chart for recommended motor, battery and gearing for some of the more popular vehicles on the market.Max. Recommended Vehicle Weight : Up to 4lbsTech Notes :Monitor motor temperatures closely; overheating a motor will cause permanent damage to the magnets. Never exceed 180° F on the the motor or ESC.Water Resistant Design: Routine maintenance is recommended after running in wet conditions. Please refer to this document for running and maintaining motors in wet environments.Comparable Turn Count : 2-Pole Equivalent Turn-Count Data Sheet
