Product Detail

Motor RPM/V (KV): 980 Motor Stator Diameter (mm): 22 Motor Magnet Length (mm): 16 Motor Shaft Diameter (mm): 3.2 Motor Mounting Holes Pitch: 16/21 Motor Weight (g): 70 Motor Resistance (Ri)(mOhm): 81 Motor Idle Current (Io) @10V (A): 0.70 Motor No.of Cells (LiPo): 2-3 Motor Max. Efficiency Current (A): 17 Motor Max. Burst Current (15s)(A): 24 Motor Approximate Max. Power (15s) (W): 260 Motor Input Connectors: DB3 Motor Recommended ESC: XC2512BA Motor Prop. Range: 10x5 to 12x6 Motor App. Class (g): 600-1200 Dimensions (L x W x D) (mm): 67x 25x 7 Weight, with wires (g): 38 Number of Cells (NiXX): 5-9 cells, 6-10.8V Number of Cells (LiPo): 2-3s, 7.4-11.1V Resistance(Ri)(Ohm): 0.0026 Max Cont. Current & Max Cont.Output: 45A, 500W Max Burst Current & Max Burst Output: 60A, 666W BEC / Dissipative Power: 5.2V/3A (Linear) Programmable: Throttle + ProgCARD V2 Signal Wire: 300MM JR
