Role:Multi-role stealth fighterFirst Flight:December 16, 2006Crew:F-35A CTOL: 1F-35B STOVL: 1F-35C CV: 1Powerplant: F-35A: 1 x Pratt & Whitney F135-PW-100, 40,000 lbs thrust with afterburner,25,000 lbs without.F-35B: 1 x Pratt & Whitney F135-PW-600, 38,000 lbs thrust with afterburner,26,000 lbs without and 40,500 lbs vertical.F-35C: 1 x Pratt & Whitney F135-PW-100, 40,000 lbs thrust with afterburner,25,000 lbs without.Internal Fuel Capacity: F-35A: 18,250 lbs (8,278 kg)F-35B: 13,500 lbs (6,125 kg)F-35C: 19,750 lbs (8,960 kg)Weights:Empty: F-35A: 29,300 lbs (13,000 kg)F-35B: 32,300 lbs (14,700 kg)F-35C: 34,800 lbs (15,800 kg)Maximum:F-35A: 70,000 lbs (31,800 kg)F-35B: 60,000lbs (27,300 kg)F-35C: 70,000 lbs (31,800 kg)Dimensions:F-35A: Length: 51.4 ft (15.7 m)Wingspan: 35 ft (10.7 m)Height: 14.4 ft (4.38 m)F-35B: Length: 51.2 ft (15.6 m)Wingspan: 35 ft (10.7 m)Height: 14.3 ft (4.36 m)F-35C: Length: 51.5 ft (15.7 m)Wingspan: 43 ft (13.1 m)Height: 14.7 ft (4.48 m)Performance:Speed with full internal weapons load: F-35A: Mach 1.6F-35B: Mach 1.6F-35C: Mach 1.6Combat Radius with internal fuel:F-35A: 590 nm (1,093 km)F-35B: 450 nm (833 km)F-35C: 600 nm (1,100 km)Range with internal fuel:F-35A: 1,200 nm (2,200 km)F-35B: 900 nm (1,667 km)F-35C: 1,200 nm (2,200 km)Weapons (Standard Internal):F-35A: 1 x 25 mm GAU-22/A cannon2 x AIM-120C air-to-air missiles2 x 2,000 pound GBU-31 JDAM guided bombsWeapons Payload:18,000 lbs (8,160 kg)F-35B: 2 x AIM-120C air-to-air missiles2 x 1,000 lb GBU32 JDAM guided bombsF-35C: 2 x AIM-120C air-to-air missiles2 x 2,000 pound GBU-31 JDAM guided bombs
